Stainless Steel 316 Rigging Toggle 1/2" (12mm) Marine Grade
Write a Review
Stainless Steel 316 Rigging Toggle 1/2" (12mm) Marine Grade
STAINLESS STEEL (316) Rigging Toggle 1/2" (12mm) Marine Grade
This is for one (1) quality marine grade stainless steel (AISI 316) rigging toggle. Each rigging toggle is laser etched with the makers mark and stamped with the grade of 316. The size of 1/2" (12mm) refers to the pin size. Not to be used for overhead lifting.
AISI 316 stainless is a premium grade of stainless and is considered by many to be best in class. 316 stainless is corrosion resistant and very durable even in the harshest of conditions.
Item will ship via USPS.
See my other listings to save on shipping...after the first item with a shipping and handling charge, additional items (except free of course) are charged a reduced rate for shipping and handling.
More information on our range is as follows:
| Rigging Toggle 316 Stainless (Type 3400) | ||||||
| Size | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) | BL (lbs) |
| 1/4" | 41 | 5 | 6.6 | 5.9 | 7.5 | 2750 |
| 5/16" | 49.7 | 6 | 9 | 7.9 | 9.9 | 3700 |
| 3/8" | 54.9 | 6.7 | 10 | 8.9 | 12 | 6800 |
| 1/2" | 77.7 | 9 | 13.1 | 11.9 | 13 | 12500 |
See photo for dimensions legend.
Not to be used for overhead lifting.
